BLUETTI 200W Solar Panel Portable for Power Station



📣 Pictures are used for illustration ONLY, please refer to the actual model and user manual. Do NOT mix different models.

Efficient & Secure



• High cell efficiency up to 23.4%
• Maximize electricity production in the available area
• Over-charge protection
• Over-current protection
• Over-temperature protection



Long-lasting & Portable



• ETFE laminate: durable & scratch-resistant & splash-Proof
• Junction box: IP65 Water-Resistant
• Zippered Pouch: hold the 120''-long cable with the MC4 connector end
• Ideal for outdoor adventures



Note: Please don't soak it in the water or leave it in the rain.

Adjustable Kickstand



• Flexible & easy set-up
• 3 levels of adjustments
• Range: 40°— 45°— 50°
• Get 25%~30% more of sunlight than lying flat
• Easy to store, space-efficient





• 【HIGHER CONVERSION RATE】 BLUETTI PV200 is a 200-Watt monocrystalline solar panel with a higher conversion efficiency of up to 23.4%, compared with the market average 20%~23%. It will produce more kilowatt-hours of electricity in the available area, and performs better even in low-light conditions.
• 【DURABLE & SPLASHPROOF】 With long-lasting ETFE material on the surface, it becomes more hard-wearing and scratch-resistant, while the IP65 waterproof standard makes it ideal for outdoor activities such as camping, fishing, hiking. (Please do not soak it in the water.)
• 【WIDELY COMPATIBLE】 The versatile PV200 solar panel is equipped with the MC4 connector and is designed to be compatible with most solar generators on the market, especially works well with BLUETTI AC200P/EB240/EB150/EB55/EB70/AC50S/EP500 power stations.
• 【FOLDABLE & PORTABLE】 With a folded size of 23.2 x 24.8 inches and 16.1 lbs of weight, the BLUETTI PV200 is convenient to carry around and easy to be set up for anyone anywhere.
• 【WHAT YOU GET】 1 x BLUETTI PV200 200W solar panel (with 120 inches cable + MC4 connector, adjustable kickstand), 1 x User Manual.

📢 📢 📢Not sure how to choose the fittest power station? Use the Power Estimate Calculator. FAQ

Q1: Why does my PV200 cannot provide 200W of output power?

A: The actual output power will be affected by many factors such as weather, temperature, sunlight intensity, and the panel's angle. The 200W of power is the result under perfect conditions. So to get a higher output wattage, please use it under stronger sunlight, adjust the angle, and avoid the shadow.

Q2: What can this PV200 charge?

A: 1 piece of PV200 is ideal for charging BLUETTI EB55/EB70/AC50S portable power stations. It also can charge most power stations on the market. But you need to purchase the MC4 to Anderson adapter if your power station's input port is Anderson.

Q3: How many PV200 do I need to charge the BLUETTI AC200P?

A: We recommend connecting 3~5 pieces of PV200 to charge the AC200P. Please note that 1 x PV200 CANNOT charge the AC200P due to the input OCV requirement.

Q4: Do I need to purchase an extra controller or cables to charge my BLUETTI EB55/EB70?

A: No. EB55/EB70 has a built-in MPPT controller, which can maximize the input power, while the MC4 connectors are compatible with each other.

Technical Details Model PV200 Peak Power 200W Lamination ETFE Cell Efficiency Up to 23.4% Max. Power Voltage (Vmp) 20.5V Max. Power Current (Imp) 9.7A Open Circuit Voltage (Voc) 26.1V Short Circuit Current (Isc) 10.3A Operating Temperature 14°F~150°F / -10°C~65°C Dimension (Unfolded) 23.2'' x 89.2'' / 590mm x 2265mm Dimension (Folded) 23.2'' x 24.8'' / 590mm x 630mm Weight 16.1LB / 7.3Kg

    BLUETTI Portable Power Station BLUETTI Portable Power Station BLUETTI Portable Power Station BLUETTI Portable Power Station BLUETTI Portable Power Station BLUETTI Portable Power Station Phone (10Wh) 50 Charges 65 Charges 170 Charges 170 Charges 340 Charges 261 Charges Laptop (60Wh) 8 Charges 10 Charges 28 Charges 28 Charges 56 Charges 43Charges CPAP (40W) 12 Hrs 16 Hrs 40 Hrs 40 Hrs 80 Hrs 65 Hrs Mini Fridge (60W) 8 Hrs 11 Hrs 28 Hrs 28 Hrs 56 Hrs 43 Hrs TV (80W) 6 Hrs 8 Hrs 20 Hrs 20 Hrs 40 Hrs 32 Hrs Projector (100W) 5 Hrs 6 Hrs 17 Hrs 17 Hrs 34 Hrs 26 Hrs Desktop PC (200W) 2.5 Hrs 3 Hrs 8.5 Hrs 8.5 Hrs 17 Hrs 13 Hrs Hair Dryer (1500W) - - 1.2 Hrs 1.2 Hrs 2.4 Hrs 1.7 Hrs Coffee Maker (2000W) - - 68 Cups 68 Cups 136 Cups 87 Cups A/C (8000BTU) - - 3-7 Hrs 3-7 Hrs 6-14 Hrs 2-7 Hrs
